New Original Fujifilm Dimatix Starfire SG1024 L3F 80pl

New Original Fujifilm Dimatix Starfire SG1024 L3F 80pl


Specifications:

This printhead provides a range of capabilities uniquely designed in support of these demanding application and to ensure the productivity and reliability that are needed in production environment.

To meet those requirements the FUJIFILM STARFIRE SG1024 L3F print head are designed to provide resistance to the aggressive fluids used in sand casting and metal sintering. The printhead also boasts fluid recirculation at the nozzle plate level and well serviceable components that allow our OEM partners to maximize the usable life of these printheads.

SKU: SG1024L3F
Manufacturer part number: SG1024L3F
Manufacturer: Dimatix
HTS Code: [EU] 84439990
This printhead carries a manufacturer warranty.
Country of origin : Japan


Product Data :

Number of addressable jets / module : 1024
Print width : 64.96mm (2.55in)
Native resolution : 400dpi
Native drop size/largest drop size : 80pl / 200pl
VersaDrop™ Max Productivity: 1200ng kHz
Firing frequency : Up to 20kHz
Inkjet operating temperature range : Up to 50C (122F)
Nominal fluid viscosity : 8-20cP (10-14cP recommended)
Compatible jetting fluids : UV-curable, organic solvents and aqueous inks
Nozzle Plate technology : Metal
Printhead heat type : Integrated heater, thermal transfer
OEM accessible non-volatile memory : 64 byte rewritable
Integral temperature sensor : Included


Features:

Unique Design:

- 400DPI resolution with drop sizes ranging from 80-200pl that allow for optimal and efficient use of binder fluids
- Reliably use challenging jetting fluids used for binding materials in sand casting and metal sintering
- This product line can be used for prototyping and production
- FUJIFILM Dimatix 10+ years of continued innovations in additive manufacturing


Productivity:

- REDIJET® - Double Recirculation for reliable jetting & Support fast system start-up
- Maximize Uptime for high productivity and return on investment
- Enables robust system design for end user up-time and productivity


Reliability:

- Industrial capabilities meet customer demands in production environments
- Robust (repairable) printhead for up-time productivity
- Cost-effective repairs and maintenance
