SPT‑1020 35PL Printhead Original Made In Japan

Availability: In stock
Description: Brand New
SKU: PPHSE18907
Manufacturer: Oki
HTS Code: [EU] 84439990
Country of origin : Japan
This printhead carries a manufacturer warranty.
Package：Original Manufacture Package

The Seiko SPT510 drop on demand piezo printhead is compatible with a wide-range of grand-format digital printers. Fully equipped with 510 active nozzles for high-resolution (720dpi) and high-speed (50 pl) printing and steel-plate protection for a longer life, this durable printhead lasts 4-5 times longer than many common128 printheads.


Specifications

☑️ Active Nozzles: 1,020
☑️ Nozzle Density: 185 npi
☑️ Print Swathe Width: 71.9 mm
☑️ Native Resolution: 360 dpi
☑️ Maximum Resolution: 720 dpi
☑️ Firing Frequency: 6.46 kHz or 8.29 kHz
☑️ Drop Size: 35 picoliters
☑️ Ink Compatibility: Solvent inks, eco‑solvent inks, UV‑curable inks
☑️ Design Features: Internal ink circulation system to reduce clogging, modular structure for multi‑head integration, industrial‑grade durability
☑️ High Precision & Speed: Large number of nozzles with stable firing frequency ensures fast output without sacrificing quality.
☑️ Grayscale Printing Capability: Smooth image transitions and accurate color reproduction.
☑️ Durability: Long service life suitable for continuous industrial production.
☑️ Wide Ink Compatibility: Works with solvent, eco‑solvent, and UV inks.
☑️ Reduced Maintenance: Internal ink circulation minimizes clogging risk.


Printer compatibility :
✅ Icontek: TW‑3306FB, TW‑3306FD, TW‑3306FZ, TW‑3306HB, TW‑3308FB, TW‑3308FD, TW‑3308FZ, TW‑3308HB, TW‑5308FZ, TW‑3308RS, TW‑3304XB, TW‑3306X, TW‑3308MB, TW‑3200F3, M5, M7
✅ Infiniti Challenger: FY‑3208GS, FY‑5008GS, FY‑UV2508S


Model           | Drop Size | Nozzle No. | Firing Frequency | Nozzle Width | Ink Type
-------------------------------------------------------------------------------------
SPT51035PL      | 35PL      | 510        | 12.8KHZ          | 71.8mm       | solvent ink
SPT510-50PL     | 50PL      | 510        | 6KHZ             | 71.8mm       | solvent ink
SPT1020-35PL    | 35PL      | 1020       | 8.29KHZ          | 71.8mm       | solvent ink
SPT508GS-12PL   | 12PL      | 508        | 11/17.4KHZ       | 71.8mm       | eco solvent/UV ink
SPT225-35PL     | 35PL      | 225        | 8KHZ             | 35.8mm       | solvent ink
SPT225-12PL     | 12PL      | 225        | 12KHZ            | 35.8mm       | eco solvent/UV ink
