Ricoh Gen 5 N221414b UV Printhead with 240mm for Quantum Matan 5m
zoom_in
  • New
  • Ricoh Gen 5 N221414b UV Printhead with 240mm for Quantum Matan 5m
  • Ricoh Gen 5 N221414b UV Printhead with 240mm for Quantum Matan 5m

Ricoh Gen 5 N221414B UV Printhead with 240mm Cable 45163642 / 45209015

$1,595.00

EFI ASSY, PRINTHEAD,GEN 5,POSITION A/B, H3/H5 - 45163642 / 45209015


Availability: In stock
Description: Brand New
SKU: PPHRI18049
Manufacturer part number: 45163642 / 45209015 /N221414B
Manufacturer: EFI
HTS Code: [EU] 84439990
Country of origin : Japan
Package：Original Manufacture Package
Warranty : This printhead carries a manufacturer warranty.

Quantity

This original EFI printhead (EFI part number 45163642 / 45209015, Ricoh part number N221414B) is suitable for a range of EFI printers. This printhead is 310mm long in total (head body + cable + connectors). The head cable is 240mm long.



Specifications
☑️Dimensions: 89 x 25 x 69 mm (excluding cables)
☑️Head materials: SST, Nickel alloy and Epoxy Adhesive
☑️Nozzle plate surface: Coated SST
☑️Number of nozzles: 4 x 320 nozzles
☑️Nozzle spacing: 0.1693 mm
☑️Nozzle density: up to 600 npi
☑️Piezo type: D33 Stacked PZT
☑️Temperature control: Integrated Heater and Thermistor
☑️Operator temperature range: Up to 80° C
☑️Native drop volume: 7 pl
☑️Drop volume range: 7 - 35 pl
☑️Drop velocity: 7 m/s
☑️Jetting frequency: Up to 60 kHZ
☑️Ink compatibility: UV Inks
☑️Life: 100 billion actuations per nozzle



Printer compatibility :
✅ Quantum Matan 5m
✅ EFI Vutek 5R
✅ EFI Vutek H3
✅ EFI Vutek H5
✅ EFI Vutek 5r Plus
