Original MUTOH DF-49684 Eco Solvent UV Printhead Green Edge

This VJ-1604 printhead is suitable for Mutoh ValueJet printer series printers. This original Mutoh printhead is solvent based and has a 24 digit head ID. Please refer to DF-49029 for the 40 digit head ID water based Mutoh printhead.
The VJ-1604 printhead has a native resolution of 1440dpi, 8 nozzle lines (corresponding with 8 independent ink channels) and 180 nozzles per line.
The VJ-1604 printhead is either used in 4-colours (2 channels per colour) and has a minimum, variable droplet size of 1.5 pico litre (max. droplet size is 21 pico litre). The typical firing frequency for this print head is 8 kHz.
This generation of printheads allows fast speed, high resolution printing with eco-solvent and mild solvent inks. This VJ-1604 original printhead is delivered in a sealed Mutoh package. Mutoh part number for this print head is DF-49684.
This green connector printhead replaces the black connector printhead DF-49029 for Drafstation printers. It is 100% compatible and recommended by Mutoh. The DF-49029 was discontinued and is not available anymore.

DF-49684 and DH-40990 printheads are compatible with VJ-1604X printer models.


Specifications
☑️Technology: Micro-Piezo
☑️Native resolution: 1440 dpi
☑️Min. Droplet Size: 1.5 pico litre
☑️Max. Droplet Size: 21 pico litre
☑️Tot. Amount of Nozzles: 1440 (8 lines x 180 nozzles)
☑️Firing Frequency: 8 kHz
☑️Ink Compatibility: eco-solvent and mild solvent

We recommend to change the head cables when installing a new printhead.



Printer compatibility :

✅ A-Tex Ultrajet S1500E
✅ A-Tex Ultrajet S1625E
✅ Mutoh RJ-900C (Draftstation)
✅ Mutoh RJ-900X (Draftstation)
✅ Mutoh RJ-901C (Draftstation Pro)
✅ Mutoh RJ-901M (Draftstation Pro)
✅ Mutoh RJ-901X (Draftstation Pro)
✅ Mutoh ValueJet 1204
✅ Mutoh ValueJet 1304
✅ Mutoh ValueJet 1304W
✅ Mutoh ValueJet 1604
✅ Mutoh ValueJet 1604W
✅ Mutoh ValueJet 1604X
✅ Mutoh ValueJet 1614
✅ Xerox 7142
