Dimatix Starfire SG1024 LA2C Printhead for Tecwin Flora Witcolor

StarFire SG1024/LA2Ci Printhead

Dimatix Starfire SG1024 LA2C Printhead for Tecwin Flora Witcolor

SKU: SG1024/LA2CI

Manufacturer part number: SG1024/LA2CI

Manufacturer: Dimatix

HTS Code: [EU] 84439990

This printhead carries a manufacturer warranty.

Country of origin : Japan

The StarFire™ SG1024/LA2Ci is a compact, self-contained unit built to withstand demanding industrial textile and other applications. It uses field proven materials to deliver consistent output over a long service life with continuous ink re-circulation and two-color operation at 200 dots-per-inch. Equipped with a single replaceable metal nozzle plate that is designed to withstand abrasion and resist damage. The unit is compatible with solvent, UV-curable and aqueous ink formulations.

Each SG1024/LA printhead has two separate ink paths each with 512 independent channels arranged in 4 rows in a single nozzle plate for resolutions up to 200 dpi. All 1024 nozzles can be fired. We recommend to change the head cables when installing a new printhead.

The StarFire™ SG1024/LA2CI and SG1024/LA2C are the same printheads.

Features:

Number of addressable Jets per module: 1024

Print width: 64.96mm (2.55")

Native resolution: 200 dpi percolor and interlaced for a 400 dpi swatch

Native drop size: 80pl

Largest drop size: 200pl

VersaDrop™ max productivity: 1500ng-kHz with drop sizes between 80 & 200ng

Fire frequency: Up to 20 kHz

Inkjet operating temperature range: Up to 50°C (122°F)

Nozzle Plate technology: Metal

Printhead heat type: Integrated heater, thermal transfer

OEM accessible non-volatile memory: 64 byte rewriteable

Integral temperature sensor: Integrated

Nominal fluid viscosity: 8-20 cP (10-14 cP recommended)

Compatible jetting fluids: UV-curable, organic solvents, and aqueous inks
